k8s on Windows Devbox - Part 0.2

Posted on October 12, 2020 in DevOps
Updated: November 09, 2020

This blog is part of a serie:

I want to install OpenFaaS again.
This time running on Kubernetes (k8s), Docker Desktop, Windows Home 10 with Virtual Machine Platform on WSL2.
Running Docker Desktop with WSL2 backend has many improvements over alternatives.
Last time I installed Docker (in this blog), I was running on Docker Swarm, Docker CE, Windows Pro 10 and Hyper-V.

@alexellisuk has build great tools. One being Arkade.
It is great for installing lots of K8s goodies both locally and in cloud. It also includes OpenFaaS.

Install k8s and Arkade on devbox on Windows

Prerequisites.

You need Docker. Start by typing

docker -v

to see if you already have it installed.
If not then follow this tutorial to get it.
In that blog I ended up with Docker Desktop on Windows Home 10 with Virtual Machine Platform incl. WSL2.

About

About Akade

What is Arkade?
Your one-stop CLI for Kubernetes (its slogan)

I'll use arkade for installing various k8s CLIs and Apps.

About K8S clusters

Now that we have Docker, then it is time to play with Arkade to install k8s and other stuff

But there are other options than Arkade to install k8s

So why use Arkade to install k8s?

  • If you only need a single node cluster then option 3 - using Docker Desktop automates the work you manually can do with Minikube.
  • If you need a multi node cluster then option 0 - using Arkade automates the work you manually can do with Kind.
  • Arkade also automates the work you need to do with other k8s related tools.

Already have a k8s cluster?

k8s install is only the top of the iceberg of Arkade.
If you already have a k8s cluster then Arkade kicks in by installing lost of

  • k8s apps from e.g. Helm Hub (with ark install) and/or
  • CLIs for k8s or apps (with ark get)

Arkade then unifies fetching packages across platforms.
Before you would use package tools like:

  • apt-get on some Linux versions
  • yum on some other Linux versions
  • choco on Windows
  • brew on Mac

and having to deal with all their parameters.

Under the hood Arkade simplifies commands by using Helm as the k8s package manager and kubectl commands.

Install Arkade

# Check that curl is installed
curl --version
# curl 7.67.0 (x86_64-w64-mingw32) libcurl/7.67.0 OpenSSL/1.1.1d (Schannel) zlib/1.2.11 libidn2/2.3.0 nghttp2/1.39.2
# Release-Date: 2019-11-06
# Protocols: dict file ftp ftps gopher http https imap imaps ldap ldaps pop3 pop3s rtsp smtp smtps telnet tftp
# Features: AsynchDNS HTTP2 HTTPS-proxy IDN IPv6 Kerberos Largefile libz Metalink MultiSSL NTLM SPNEGO SSL SSPI TLS-SRP

# Check that docker is installed
docker -v
# Docker version 19.03.12, build 48a66213fe

# Check that a k8s cluster is not yet installed
kubectl version
# Client Version: version.Info{Major:"1", Minor:"16+", GitVersion:"v1.16.6-beta.0", GitCommit:"e7f962ba86f4ce7033828210ca3556393c377bcc", GitTreeState:"clean", BuildDate:"2020-01-15T08:26:26Z", GoVersion:"go1.13.5", Compiler:"gc", Platform:"windows/amd64"}
# Unable to connect to the server: dial tcp [::1]:8080: connectex: No connection could be made because the target machine actively refused it.

# Check that arkade is not installed
arkade --help
# bash: arkade: command not found

# Install Arkade on Windows
# https://github.com/alexellis/arkade#get-arkade
curl -sLS https://dl.get-arkade.dev | sh
# Downloading package https://github.com/alexellis/arkade/releases/download/0.6.12/arkade.exe as //arkade.exe
# curl: (23) Failed writing body (0 != 16360)

# Trying as-admin
curl -sLS https://dl.get-arkade.dev | sh
# Downloading package https://github.com/alexellis/arkade/releases/download/0.6.12/arkade.exe as //arkade.exe
# chmod: cannot access '//arkade.exe': No such file or directory
# Download complete.

# Running with sufficient permissions to attempt to move arkade to /c/Users/Soren/bin
# mv: cannot stat '//arkade.exe': No such file or directory
# ln: failed to create symbolic link '/c/Users/Soren/bin/ark': No such file or directory
# Creating alias 'ark' for 'arkade'.
# main: line 172: arkade: command not found

Both attemps failed - instead get manual recipe from get.sh

  1. Open your web browser and go to https://github.com/alexellis/arkade/releases
  2. Download the latest release for windows to C:\Users\yourusername.arkade\bin\arkade`
  3. Add path to environment
    setx PATH "%path%;C:\Users\yourusername\.arkade\bin"
  4. Create a symbolic link
export ALIAS_NAME="ark"
export REPO=arkade
export BINLOCATION="/c/users/yourusername/.arkade/bin"
chmod +x "$BINLOCATION/$REPO"
ln -sf "$BINLOCATION/$REPO" "$BINLOCATION/$ALIAS_NAME"

# Did it work?
arkade version
#             _             _
#   __ _ _ __| | ____ _  __| | ___
#  / _` | '__| |/ / _` |/ _` |/ _ \
# | (_| | |  |   < (_| | (_| |  __/
#  \__,_|_|  |_|\_\__,_|\__,_|\___|
# Get Kubernetes apps the easy way
# Version: 0.6.12
# Git Commit: 0415b5fa9d0a6740feb3d9093b7555d38c7e1a51

ark get --help
# The get command downloads a CLI or application from the specific tool's releases or downloads page.
# The tool is usually downloaded in binary format and provides a fast and easy alternative to a package manager.

# Usage:
#   arkade get [flags]

# Examples:
#   arkade get helm
#   arkade get linkerd2 --stash=false

# See which CLIs arkade can install:
ark get
# Use "arkade get TOOL" to download a tool or application:
# faas-cli
# helm
# kubectl
# kubectx
# kind
# k3d
# k3sup
# kubeseal
# inletsctl
# osm
# linkerd2
# kubebuilder
# kustomize
# doctl
# k9s
# civo
# terraform

Great - we have Arkade now.

Install k8s cluster

Now lets install a k8s cluster.

# We need kubectl to manage k8s. Install it:
arkade get kubectl
# Downloading kubectl
# https://storage.googleapis.com/kubernetes-release/release/v1.18.0/bin/windows/amd64/kubectl.exe
# Tool written to: C:\Users\yourusername/.arkade/bin/kubectl.exe

# Did it install?
kubectl version
# Client Version: version.Info{Major:"1", Minor:"19",

# We will use kind to create a k8s cluster, but first install it:
arkade get kind
# Downloading kind
# https://github.com/kubernetes-sigs/kind/releases/download/v0.9.0/kind-windows-amd64
# Tool written to: C:\Users\yourusername/.arkade/bin/kind.exe
kind version
# kind v0.9.0 go1.15.2 windows/amd64

# Crate a k8s cluster:
kind create cluster
# Creating cluster "kind" ...
#  β€’ Ensuring node image (kindest/node:v1.19.1) πŸ–Ό  ...
#  βœ“ Ensuring node image (kindest/node:v1.19.1) πŸ–Ό
#  β€’ Preparing nodes πŸ“¦   ...
#  βœ“ Preparing nodes πŸ“¦
#  β€’ Writing configuration πŸ“œ  ...
#  βœ“ Writing configuration πŸ“œ
#  β€’ Starting control-plane πŸ•ΉοΈ  ...
#  βœ“ Starting control-plane πŸ•ΉοΈ
#  β€’ Installing CNI πŸ”Œ  ...
#  βœ“ Installing CNI πŸ”Œ
#  β€’ Installing StorageClass πŸ’Ύ  ...
#  βœ“ Installing StorageClass πŸ’Ύ
# Set kubectl context to "kind-kind"
# You can now use your cluster with:
kubectl cluster-info --context kind-kind
# Kubernetes master is running at https://127.0.0.1:52295
# KubeDNS is running at https://127.0.0.1:52295/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy
# To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

# And what is the name of cluster?
kind get clusters
# kind

# If you need to delete your cluster:
# kind delete cluster
# kind delete cluster --name kind

# Seems like I have a client version from docker and a server version is in the cluster with the version installed by arkade.
kubectl version
# Client Version: version.Info{Major:"1", Minor:"16+", GitVersion:"v1.16.6-beta.0", GitCommit:"e7f962ba86f4ce7033828210ca3556393c377bcc", GitTreeState:"clean", BuildDate:"2020-01-15T08:26:26Z", GoVersion:"go1.13.5", Compiler:"gc", Platform:"windows/amd64"}
# Server Version: version.Info{Major:"1", Minor:"19", GitVersion:"v1.19.1", GitCommit:"206bcadf021e76c27513500ca24182692aabd17e", GitTreeState:"clean", BuildDate:"2020-09-14T07:30:52Z", GoVersion:"go1.15", Compiler:"gc", Platform:"linux/amd64"}

# Check cluster location and credentials that kubectl knows about:
kubectl config view
# apiVersion: v1
# clusters:
# - cluster:
#     certificate-authority-data: DATA+OMITTED
#     server: https://127.0.0.1:55555
#   name: kind-kind
# contexts:
# - context:
#     cluster: kind-kind
#     user: kind-kind
#   name: kind-kind
# current-context: kind-kind
# kind: Config
# preferences: {}
# users:
# - name: kind-kind
#   user:
#     client-certificate-data: REDACTED
#     client-key-data: REDACTED

kubectl get nodes
# NAME                 STATUS   ROLES    AGE   VERSION
# kind-control-plane   Ready    master   18m   v1.19.1

kubectl get pods
# No resources found in default namespace.

The cluster config seen in kubectl config view is stored in C:\Users\youruserid.kube\config
When you want to connect to other clusters you need to modify or replace that file.
In the file one cluster will be your default.

So now having a master node running and no pod what is next?

  • We could add worker nodes to the cluster
  • We could install apps

Issues:

  • Booting Windows made bash unable to access cluster. Why?
    • It was not an envir var problem, since after delete + create cluster then no new envir vars were created
    • In vid Walk-through of arkade - for Kubernetes, Alex think boot persistence has been implemented - and before we had to recreate cluster after boot.
    • Tips about accessing clusters: Accessing Clusters
    • Perhaps you just need to start the master node: docker start kind-control-plane

Stop and start the cluster

# stop the k8s cluster
docker stop kind-control-plane

# check if k8s cluster is running
kubectl cluster-info
# Unable to connect to the server: dial tcp 127.0.0.1:52295: connectex: No connection could be made

# Check if there are any clusters
$ kind get clusters
# kind

# Check it the container is running
docker ps -a | grep kind
# CONTAINER ID        IMAGE                  COMMAND                  CREATED             STATUS                   PORTS                       NAMES
# 0b9a7220b4f8        kindest/node:v1.19.1   "/usr/local/bin/entr…"   5 weeks ago         Exited (0) 3 weeks ago   127.0.0.1:52295->6443/tcp   kind-control-plane

# start the k8s cluster
docker start kind-control-plane

# check if k8s cluster is running
kubectl cluster-info
# Kubernetes master is running at https://127.0.0.1:52295
# KubeDNS is running at https://127.0.0.1:52295/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

Install k8s apps

Arkade makes it easy to install many ready-to-use apps. You can print the list it contains:

# Check which apps arkade lets you easily install:
ark install --help
# Install Kubernetes apps from helm charts or YAML files using the "install" command.

# You can also find the post-install message for each app with the "info" command.

# Usage:
#   arkade install [flags]
#   arkade install [command]

# Examples:
#   arkade install
#   arkade install openfaas  --gateways=2
#   arkade install inlets-operator --token-file $HOME/do-token

# Available Commands:
#   argocd                  Install argocd
#   cert-manager            Install cert-manager
#   chart                   Install the specified helm chart
#   cron-connector          Install cron-connector for OpenFaaS
#   crossplane              Install Crossplane
#   docker-registry         Install a Docker registry
#   docker-registry-ingress Install registry ingress with TLS
#   gitea                   Install gitea
#   grafana                 Install grafana
#   info                    Find info about a Kubernetes app
#   ingress-nginx           Install ingress-nginx
#   inlets-operator         Install inlets-operator
#   istio                   Install istio
#   jenkins                 Install jenkins
#   kafka-connector         Install kafka-connector for OpenFaaS
#   kube-image-prefetch     Install kube-image-prefetch
#   kube-state-metrics      Install kube-state-metrics
#   kubernetes-dashboard    Install kubernetes-dashboard
#   linkerd                 Install linkerd
#   loki                    Install Loki for monitoring and tracing
#   metrics-server          Install metrics-server
#   minio                   Install minio
#   mongodb                 Install mongodb
#   nats-connector          Install OpenFaaS connector for NATS
#   nfs-client-provisioner  Install nfs client provisioner
#   openfaas                Install openfaas
#   openfaas-ingress        Install openfaas ingress with TLS
#   openfaas-loki           Install Loki-OpenFaaS and Configure Loki logs provider for OpenFaaS
#   osm                     Install osm
#   portainer               Install portainer to visualise and manage containers
#   postgresql              Install postgresql
#   redis                   Install redis
#   registry-creds          Install registry-creds
#   tekton                  Install Tekton pipelines and dashboard
#   traefik2                Install traefik2

# Flags:
#   -h, --help                help for install
#       --kubeconfig string   Local path for your kubeconfig file (default "kubeconfig")
#       --wait                If we should wait for the resource to be ready before returning (helm3 only, default false)

Install k8s app kubernetes-dashboard

kubernetes-dashboard gives you a GUI for viewing what your cluster contains. Let's install it:

arkade install kubernetes-dashboard
# Using kubeconfig: C:\Users\youruserid/.kube/config
# Node architecture: "amd64"
# # To create the Service Account and the ClusterRoleBinding
# # @See https://github.com/kubernetes/dashboard/blob/master/docs/user/access-control/creating-sample-user.md#creating-sample-user

cat <<EOF | kubectl apply -f -
---
apiVersion: v1
kind: ServiceAccount
metadata:
    name: admin-user
    namespace: kubernetes-dashboard
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
    name: admin-user
roleRef:
    apiGroup: rbac.authorization.k8s.io
    kind: ClusterRole
    name: cluster-admin
subjects:
- kind: ServiceAccount
    name: admin-user
    namespace: kubernetes-dashboard
---
EOF

# #To get your Token for logging in
kubectl -n kubernetes-dashboard describe secret $(kubectl -n kubernetes-dashboard get secret | grep admin-user-token | awk '{print $1}')
# Shown last part of the output
# Name:         admin-user-token-8ltkm
# Namespace:    kubernetes-dashboard
# Labels:       <none>
# Annotations:  kubernetes.io/service-account.name: admin-user
#               kubernetes.io/service-account.uid: cf8c00d4-e353-46cd-a60f-52b976278a5c

# Type:  kubernetes.io/service-account-token

# Data
# ====
# ca.crt:     1066 bytes
# namespace:  20 bytes
# token:      eyJhbGciOiJSUzI1NiIsImtpZCI6InBXbUdUMG01cHU1b21mWl9HQ2hvckpnc2piTE8xZFhraE16Qnl6b0FUYWsifQ.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.HOkirmDW_KEpNcH_W2kotH5V_r_MgxzMiZnYctyP2bdCt7yBZijfwVK6rv3SuYizZM5FuxWsHARR8aFmsIG5wtL4Pv1mS0wHggt1Tt3rX-8Du2kj0UZwjM6pKZ5zECSC-JM1fItUAjsZyad2qxAThPaYtaJw2HVbJHdrQxn7I65kZY9qNGTPevwVrfs8PeUnpeUqlmaeZ9doob0x1zB_3TKvvST9r38m9nsRblfQU2P9QY82Q4qU74sV3lwE5cRs0XuviyQBEvfGxH5od7ahTXea5B5zHA-3_7SSyvLWHvjMMk4fn8_ZWwxJKFYc1zbxL2JqNvqzvvqRqsfbwOjX8g

# #To forward the dashboard to your local machine
kubectl proxy
# Starting to serve on 127.0.0.1:8001

# # Once Proxying you can navigate to the below
# http://localhost:8001/api/v1/namespaces/kubernetes-dashboard/services/https:kubernetes-dashboard:/proxy/#/login
# Paste the token above into the Dashboard login screen

You need to copy-paste your token from above to the login screen:

k8s dashboard login

When logged in:
k8s dashboard logged in

There are several k8s namespaces. Select some to see what they are comprised of:
k8s dashboard namespaces

Issues:

More info:

Install k8s app metrics-server (- and heml)

Metrics Server is a cluster-wide aggregator of resource usage data.

Apparently installing metrics-server does also do arkade get helm, when it is not yet installed.
Helm is a package manager for k8s apps (packaged in helm charts).

arkade install metrics-server
# Using kubeconfig: C:\Users\youruserid/.kube/config
# Node architecture: "amd64"
# Client: "x86_64", "MINGW64_NT-10.0-19041"
# 2020/09/22 12:41:45 User dir established as: C:\Users\youruserid/.arkade/
# https://get.helm.sh/helm-v3.2.4-windows-amd64.zip
# C:\Users\Soren\AppData\Local\Temp/windows-amd64
# C:\Users\Soren\AppData\Local\Temp/helm.exe
# C:\Users\Soren\AppData\Local\Temp/README.md
# C:\Users\Soren\AppData\Local\Temp/LICENSE
# 2020/09/22 12:42:19 extracted zip into C:\Users\youruserid\AppData\Local\Temp: 4 files, 0 dirs (991.479ms)
# Downloaded to:  C:\Users\youruserid/.arkade/bin/helm.exe helm.exe
# Error: no repositories found. You must add one before updating
# Error: exit code 1

helm version
# version.BuildInfo{Version:"v3.2.4", GitCommit:"0ad800ef43d3b826f31a5ad8dfbb4fe05d143688", GitTreeState:"clean", GoVersion:"go1.13.12"}

So what's with Error: no repositories found? Getting Started with Helm v3

# Verify repo (list of helm charts) is missing
helm repo update
# Error: no repositories found. You must add one before updating

# get stable repo - this can take 10s of minutes without output in the shell...
helm repo add stable https://kubernetes-charts.storage.googleapis.com/
# "stable" has been added to your repositories

On https://helm.sh/docs/intro/quickstart/ in the version dropdown you will see which version of Helm is the latest stable version, which was installed above.

Having the helm chart list downloaded we try again:

arkade install metrics-server
# Using kubeconfig: C:\Users\youruserid/.kube/config
# Node architecture: "amd64"
# Client: "x86_64", "MINGW64_NT-10.0-19041"
# 2020/09/24 17:27:20 User dir established as: C:\Users\youruserid/.arkade/
# https://get.helm.sh/helm-v3.2.4-windows-amd64.zip
# C:\Users\youruserid\AppData\Local\Temp/windows-amd64
# C:\Users\youruserid\AppData\Local\Temp/helm.exe
# C:\Users\youruserid\AppData\Local\Temp/README.md
# C:\Users\youruserid\AppData\Local\Temp/LICENSE
# 2020/09/24 17:27:22 extracted zip into C:\Users\youruserid\AppData\Local\Temp: 4 files, 0 dirs (406.024ms)
# Downloaded to:  C:\Users\youruserid/.arkade/bin/helm.exe helm.exe
# Hang tight while we grab the latest from your chart repositories...
# ...Successfully got an update from the "stable" chart repository
# Update Complete. ⎈ Happy Helming!⎈
# Chart path:  C:\Users\youruserid\AppData\Local\Temp/charts
# VALUES values.yaml
# Command: C:\Users\youruserid/.arkade/bin/helm [upgrade --install metrics-server stable/metrics-server --namespace kube-system --values C:\Users\youruserid\AppData\Local\Temp/charts/metrics-server/values.yaml --set args={--kubelet-insecure-tls,--kubelet-preferred-address-types=InternalIP\,ExternalIP\,Hostname}]
# Release "metrics-server" does not exist. Installing it now.
# NAME: metrics-server
# LAST DEPLOYED: Thu Sep 24 17:27:29 2020
# NAMESPACE: kube-system
# STATUS: deployed
# REVISION: 1
# NOTES:
# The metric server has been deployed.

# In a few minutes you should be able to list metrics using the following
# command:

#   kubectl get --raw "/apis/metrics.k8s.io/v1beta1/nodes"
# =======================================================================
# = metrics-server has been installed.                                  =
# =======================================================================

# # It can take a few minutes for the metrics-server to collect data
# # from the cluster. Try these commands and wait a few moments if
# # no data is showing.

# # Check pod usage
# kubectl top pod

# # Check node usage
kubectl top node
# Error from server (ServiceUnavailable): the server is currently unable to handle the request (get nodes.metrics.k8s.io)

# # Find out more at:
# # https://github.com/helm/charts/tree/master/stable/metrics-server

# Thanks for using arkade!

So now we have Error from server (ServiceUnavailable).
Try fix: issue 448.

# Is pod running?
kubectl get pods -n kube-system
# NAME                                         READY   STATUS    RESTARTS   AGE
# metrics-server-56c4ff648b-jdzv6              1/1     Running   0          53m

# Is service running?
kubectl get svc -n kube-system
# NAME             TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)                  AGE
# metrics-server   ClusterIP   10.106.132.12   <none>        443/TCP                  55m

3 days later ...

kubectl top node
# NAME                 CPU(cores)   CPU%   MEMORY(bytes)   MEMORY%
# kind-control-plane   473m         5%     952Mi           8%

kubectl top pod

kubectl get --raw "/apis/metrics.k8s.io/v1beta1/nodes"
# Error from server (NotFound): the server could not find the requested resource

Start proxy in another terminal

kubectl proxy

Then open browser http://127.0.0.1:8001/

{
    "paths": [
        "/apis/metrics.k8s.io",
        "/apis/metrics.k8s.io/v1beta1",

http://127.0.0.1:8001/apis/metrics.k8s.io/v1beta1/nodes gives "ERR_CONNECTION_REFUSED"

OK, I'm not done with this, but I'll fill in, when focus comes back onto it...

More info:

What's next?

I didn't get the the OpenFaaS part, yet - I'll park that for later.

I also want to build apps on a solid setup.
What I have in mind is the Bitnami stack
Bitnami stack
(Image on kubeprod.io)

I might want to add to the stack:

Some apps I have in mind could be

More Links

The End
